ELP 48MP USB Fisheye Camera Wide Angle Webcam for Computer Mini Lightburn Camera for Laser Engraver UVC USB2.0 PC Camera 6000P USB Security Camera for Raspberry pi (1.56mm fisheye Lens(200°))
Description: ELP-USB48MP02-SL185 (HFOV about 200degree)
-
High Resolution 48MP Fixed lens Wide Angle USB Camera
-
Based on big size 1/2” IMX586 image sensor, fixed focus, USB 2.0 UVC compliant camera. No extra drivers needed, the native UVC drivers of Windows, Linux, Android and Mac shall be compatible with this camera. Quickly shoot the images or record videos with super Image reality, real color reproduction. Its ultra 8000*6000 resolution can be used in a wide range of applications where high-resolution images and videos with autofocus capabilities are required.
Package include :
1 Piece of 48MP USB Camera with wide angle 1.56mm fisheye lens,metal enclosure .
1pc of 2m USB Cable
Features
*Ultra HD 48Megapixels USB Camera,max 8000(H)X6000(V) High Resolution
*High frame rate 30fps 4K camera module ,can drive 30fps @ 3840X2160
*With industrial grade high quality sensor IMX586,1/2inch .
*Wide angle Fisheye lens, 1.56mm lens FOV 200 degree. 1.95mm lens FOV about 175 degree,
M12 Mount Lens interchangeable,optional to change other M12 mount lens to work .
*Super Image reality, real color reproduction, without interpolation.
*Metal Aluminum enclosure with bracket ,easy to install and fix .
*UVC Free Driver , Plug and Play, easily used on different systems.
*Support Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi...
*Widely application :Well used for industrial camera ,video conference camera ,Online class /live broadcast, high-definition photography, face recognition, document scanning, ID Card/passpord scanning and etc
Specification
|
Model
|
ELP-USB48MP02-SL185 (1.56mm lens 200Degree)
ELP-USB48MP02-SL170 (1.95mm lens 175Degree)
|
|
Sensor
|
IMX586
|
|
Sensor Size
|
1/2 inch (4:3)
|
|
Max. Resolution
|
8K ,UHD 8000 (H) *6000 (V)
|
|
Compression format
|
MJPEG / YUV2（YUYV）
|
|
Resolution & frame
|
8000x6000 @ 5fps MJPEG / 4000x3000 @ 12fps MJPEG
3840x2160 @ 30fps MJPEG / 1920x1080 @ 30fps MJPEG
1280x720 @ 30fps MJPEG
1920*1080 @5fps YUY2 / 800*600 @25fps YUY2
640*480 @20fps YUY2
|
|
Surface Mount Technology
|
SMT
|
|
S/N Ratio |
37dB |
|
Dynamic Range |
82dB |
|
Sensitivity |
1.4V/lux-sec@550nm |
|
Mini illumination
|
0.3lux
|
|
Shutter Type
|
Electronic rolling shutter / Frame exposure
|
|
Connecting Port type
|
USB2.0 High Speed
|
|
Free Drive Protocol
|
USB Video Class（UVC）
|
|
AEC
|
Support
|
|
AWB
|
Support
|
|
Adjustable parameters
|
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Exposure
|
|
Lens Parameter
|
Size: 1/2.3”, FOV 170degree Focus 1.95mm focal length
Relative Illumination (Sensor): 70%
IR Filter: 650±10nm
(Many other lens optional)
|
|
Power supply
|
USB BUS POWER 4PIN-2.0mm socket
|
|
Operating Voltage
|
DC 5V
|
|
Working current
|
550mA - 610mA
|
|
Storage Temperature
|
-20～80℃
|
|
Working temperature
|
0～70℃
|
|
Board size /Weight
|
Double-deck, 38mm x 38mm / 200g
|
|
USB Cable
|
Supply 2m USB Cable standard ,optional 0.3m/0,5m/1m/2m .
|
|
Operating system request
|
Win XP/Vista/Win7/Win8 / Win10/ Win11 etc.
Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC
|
ELP 48MP USB camera can capture very HD High Definition Fidelity images with real shooting of fisheye wide angle viewing range
High Definition 48MP Ultra HD USB Camera, Max Resolution: 8000(H) X 6000(V) 48 Megapixel. super Image reality, real color reproduction, show your best in every video call.
Wide angle 1.56mm fisheye lens, HFOV about 200 degree, wider angle of view.
Plug&Play, Driver Free: UVC-compliant, just connect the camera to PC computer, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed.
Mini size light weight usb camera for pc, computer, laptop, raspberry pi, android development board, Jetson Nano, etc
FOR RASPBERRY PI
-
It can work with already preinstalled camera software instead of builtin camera.
-
Support Android development board,Raspberry Pi development board,Jetson Nano,etc.
FOR PC:
-
Support windows,linux,mac,Android,raspberry Pi
-
Very easy to use,UVC compliant,free driver,just plug in and go.
Available to set camera parameters according to your needs: include Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Exposure
Multiple Operation System Compatible. Support Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi...OTG Support, can be used on Android smartphone, recommended app "USB Camera".
Package include:
1pc of 48MP USB Camera with wide angle fisheye lens, metal housing,
1pc of USB Cable (Length 1m or 2m optional)
48MP Ultra HD USB Camera Widely Application
Application
this ultra clear 48mp usb camera is well used for medical device, 3D scanner, high resolution document scan, scientific research&developmrnt, education and training, etc.
Well used for industrial camera, video conferencing, live streaming, security system, medical device, industrial inspection, scientific research and development , education and training, high resolution document scan, high-speed photographic apparatus, photo scanner... and so on.
ELP USB camera module is a small camera device that connects to a computer or other device via a USB interface.
These modules typically include a camera sensor,a lens, and other necessary components to capture images or video.
How to use ?
