ELP 180 Degree Super Wide Angle Distortion Correction USB Webcam Camera Module 1080P UVC OTG USB 2.0 High Speed Webcam H.264 MJPEG

ELP 180 Degree Super Wide Angle Distortion Correction USB Webcam Camera Module 1080P UVC OTG USB 2.0 High Speed Webcam H.264 MJPEG

  • Model: ELP-USBFHD09DC-FD180
  • Availability: In stock

$56.10

Quantity:
 inquiry Now

Products Description

ELP 180 Degree Super Wide Angle Distortion Correction USB Webcam Camera Module 1080P UVC OTG USB 2.0 High Speed Webcam H.264 MJPEG

Sample effect

Key Features:

  • 1.180 degree Super wide angle ,no distortion lens, with distrotion correction function.
  • 2. Aptina AR0330 color cmos sensor
  • 3. Support H.264/MJPEG/YUYV output
  • 4. Full HD 1920*1080P resolution



Specifications:



Product Model
ELP-USBFHD09DC
(180degree Distortion Correction)
Sensor
AR0330
Lens Size
1/3 inch
Pixel Size
5.07um X 3.38um
Max resolution
1920(H)X1080(V)
Compression format
H264 /MJPEG / YUV2(YUYV)
Resolution & frame
MJPEG:
1920*1080 @30fps/1280*720 @30fp/640*480@30fps
H264:
1920*1080 @30fps 1280*720 @30fps 640*480@30fps
YUY2:
 1920*1080 @2fps 1280*720 @2fps 640*480 @30fps
S/N Ratio
39dB
Dynamic Range
72.4dB
Sensitivity
2.0V/lux-sec@550nm
Mini illumination
0. 1lux
Shutter Type
Electronic rolling shutter / Frame exposure
Connecting Port type
USB2.0 High Speed
Free Drive Protocol
USB Video Class(UVC)
Support OTG Protocol
USB2.0 OTG
Auto Exposure Control/
AEC
Support
Auto White Balance/
AEB
Support
Auto Gain Control/
AGC
Support
Adjustable parameters
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma,
Gain, White balance, Backlight Contrast, Exposure
Lens
Standard 185 degree Lens
Power supply
USB BUS POWER 4P-2.0mm Plug
Operating Voltage
DC5V
Working current
140mA~220mA
Working temperature
-10~70℃
Storage
temperature
-20~85℃
Board size /Weight
38X38mm/ about 30g
Cable Length
Standard 1 meter / Option 2/3/5 meters
