ELP USB Camera 2952X1944P HD CMOS OV5640 Sensor Free Driver Plug Play USB2.0 Camera With 5-50mm Varifocal Lens Manaual Zoom HD Video Webcam For Online Teaching
Package include
1pc 5MP USB Camera with varifocal lens (2.8-12mm / 5-50mm optional ),with 3m usb cable
Feature:
*Ultra 5MP HD USB Camera , UP to 2592 (H) x 1944 (V) resolution
*OV5640 CMOS sensor for high quality image.
*High quality lens, true and undistorted color image. 5-50mm varifocal lens, manual focus support zoom 10x
*High speed USB 2.0 interface for high resolution PC camera interface.
*Super small outline and thin profile for embedded applications.
*High frame rate–30 fps in 1280X720 resolution.
*Low power consumption – ideal for portable equipment.
*UVC for use in Linux, Windows XP, WIN CE, MAC, SP2 or above.
*Camera with UVC.
Specification:
|
Model:
|
ELP-USB500W02M-MFV(5-50mm)
|
|
Sensor
|
1/4" CMOS OV5640
|
|
Lens size
|
500W, 5.0megapixel, Max. 2592(H)x1944(V)pixels
|
|
Max. Resolution
|
2592X1944
|
|
Picture format
|
MJPEG/YUY2
|
|
USB Protocal
|
USB2.0 HS/FS, USB1.1 FS
|
|
Support free driver
|
USB Video Class(UVC)1.1
|
|
Auto exposure AEC
|
Support
|
|
Auto white blance AEB
|
Support
|
|
Frame rate
|
2592 (H) x 1944 (V) pixels MJPEG 15fps YUY2 3fps ，2048 (H) x 1536 (V) pixels MJPEG 15ps YUY2 3fps
1600 (H) x 1200 (V) pixels MJPEG 15fps YUY2 3fps ，1920 (H) x 1080 (V) pixels MJPEG 15fps YUY2 3fps
1280 (H) x 1024 (V) pixels MJPEG 15fps YUY2 7.5fps ，1280 (H) x 720 (V) pixels MJPEG 30fps YUY2 7.5fps
1024 (H) x 768 (V) pixels MJPEG 30fps YUY2 15fps ，800 (H) x 600 (V) pixels MJPEG 30fps YUY2 30fps
640 (H) x 480 (V) pixels MJPEG 30fps YUY2 30fps ，320 (H) x 240 (V) pixels MJPEG 30fps YUY2 30fps
|
|
Adjustable parameters
|
Brightness/Contrast/Color saturation /Definition/Gamma/WB
|
|
Night vision
|
optional, can choose IR board
|
|
Lens
|
5-50mm varifocal lens, optional 2.8-12mm
|
|
voltage
|
DC 5V
|
|
current
|
150mA
|
|
work temperature
|
DEGREES(-20~70)
|
|
Size
|
41*41mm
|
|
Support OS
|
WinXP/Vista/WIN7/WIN8
Linux with UVC
Mac-OS X 10.4.8 or later
Wince with UVC
Android 4.0 or above
|
ELP USB camera module is a small camera device that connects to a computer or other device via a USB interface.
These modules typically include a camera sensor,a lens, and other necessary components to capture images or video.
Applications
ELP USB camera modules can be used in a wide range of applications,
including video conferencing, security and surveillance, machine vision, and robotics.
They are often used in conjunction with computer vision software to perform tasks such asobject recognition, tracking,and analysis.
