ELP High Definition 48MP USB Camera Module 8000x6000 Free Driver USB2.0 Plug & Play No Distortion Ultral HD IMX586 Webcam With M12 Mount lens Chanegable
Description: ELP-USB48MP02 series
This High Resolution 48MP USB Camera is based on big size 1/2” CMOS IMX586 image sensor, manual focus,
USB 2.0 UVC compliant camera. No extra drivers needed, the native UVC drivers of Windows, Linux, Android and Mac shall be compatible with this camera,
shoot the images or record videos with super Image reality, real color reproduction.
Its ultra 8000*6000 resolution can be used in a wide range of applications where high-resolution images and videos with fixed focus capabilities are required.
Package include :
1 Piece of 48MP USB Camera with No Distortion lens, 1m USB Cable
Features
*Ultra HD 48Megapixels USB Camera,max 8000(H)X6000(V) High Resolution
*High frame rate 30fps 4K camera module ,can drive 30fps @ 3840X2160
*With industrial grade high quality sensor CMOS IMX586
*With No distortion fixed focus lens
M12 mount lens, it's interchangeable,optional to change other M12 mount lens to work .
*Super Image reality, real color reproduction, without interpolation.
*UVC Free Driver , Plug and Play, easily used on different systems.
*Support Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi...
*Widely application :Well used for industrial camera ,video conference camera ,Online class /live broadcast, high-definition photography, face recognition, document scanning, ID Card/passpord scanning and etc
Specification
|
Model
|
ELP-USB48MP02-V100
|
|
Sensor
|
IMX586
|
|
Sensor Size
|
1/2 inch (4:3)
|
|
Max. Resolution
|
8K ,UHD 8000 (H) *6000 (V)
|
|
Compression format
|
MJPEG / YUV2（YUYV）
|
|
Resolution & frame
|
8000x6000 @ 5fps MJPEG / 4000x3000 @ 12fps MJPEG
3840x2160 @ 30fps MJPEG / 1920x1080 @ 30fps MJPEG
1280x720 @ 30fps MJPEG
1920*1080 @5fps YUY2 / 800*600 @25fps YUY2
640*480 @20fps YUY2
|
|
Surface Mount Technology
|
SMT
|
|
S/N Ratio |
37dB |
|
Dynamic Range |
82dB |
|
Sensitivity |
1.4V/lux-sec@550nm |
|
Mini illumination
|
0.3lux
|
|
Shutter Type
|
Electronic rolling shutter / Frame exposure
|
|
Connecting Port type
|
USB2.0 High Speed
|
|
Free Drive Protocol
|
USB Video Class（UVC）
|
|
AEC
|
Support
|
|
AWB
|
Support
|
|
Adjustable parameters
|
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Exposure
|
|
Lens Parameter
|
Size: 1/2.3”, FOV: 100 Degree
Relative Illumination (Sensor): 70%
IR Filter: 650±10nm
(Many other lens optional)
|
|
Power supply
|
USB BUS POWER 4PIN-2.0mm socket
|
|
Operating Voltage
|
DC 5V
|
|
Working current
|
550mA - 610mA
|
|
Storage Temperature
|
-20～80℃
|
|
Working temperature
|
0～70℃
|
|
Board size /Weight
|
Double-deck, 38mm x 38mm / 200g
|
|
USB Cable
|
Supply 1m USB Cable standard ,optional 0.3m/0,5m/1.5m/2m .
|
|
Operating system request
|
Win XP/Vista/Win7/Win8 / Win10/ Win11 etc.
Linux with UVC (above linux-2.6.26)
MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC
|
ELP 48MP USB camera can capture very HD High Definition Fidelity images
NO Distortion camera , 48Megapixels Camera Module USB with none-distortion lens
With CMOS IMX586 Image Sensor ,offer super Image reality, real color reproduction, without interpolation .
High Frame Rate 30fps 48MP USB Camera @ 3840x2160
1m USB Cable is supplied together with the 48mp camera .
Plug and Play/Free Driver . UVC-compliant, just connect the camera to PC, laptop, Android device or Raspberry Pi with the USB cable without extra drivers to be installed.
Multiple Operation System Compatiblem . Support Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi...OTG Support, can be used on Android smartphone, recommended app "USB Camera".
Small outline and thin profile for embedded machines, Camera Board Size 38*38mml Weight: 80g . light weight camera board can be installed in most hidden and narrow position.
Application
this ultra clear 48mp usb camera is well used for medical device, 3D scanner, high resolution document scan, scientific research&developmrnt, education and training, etc.
Well used for industrial camera, video conferencing, live streaming, security system, medical device, industrial inspection, scientific research and development , education and training, high resolution document scan, high-speed photographic apparatus, photo scanner... and so on.
ELP USB camera module is a small camera device that connects to a computer or other device via a USB interface.
These modules typically include a camera sensor,a lens, and other necessary components to capture images or video.
